Xinmeng is a professional leader China Insert Plate Ballistic manufacturer with high quality and reasonable price. Welcome to contact us.
Bulletproof insert | ||||||||
Preface | Category | Picture | Technical parameters | |||||
1 | Bulletproof insert-PE | Product name | PE bulletproof chest plate (PURE PE PLATE) | |||||
Bulletproof material | Ultra-high molecular polyethylene (PE) | |||||||
Color | Black, military green, camouflage, customizable | |||||||
Dimensions | 250*300mm | 250*300mm | 250*300mm | |||||
Bulletproof area(㎡) | 0.07㎡ | 0.07㎡ | 0.07㎡ | |||||
Thickness(mm) | 6.5±0.5mm | 14.5±0.5mm | 22±0.5mm | |||||
Bulletproof level | GA3 | GA4 | GA5 | |||||
Weight KGS | 0.50±0.05KG | 1.05±0.05KG | 1.55±0.05KG | |||||
Execution standards | "GA141-2010 Police Body Armor" | |||||||
Spray painting process | Wrapping cloth or polyurea | |||||||
Delivery | Determined based on order quantity | |||||||
Performance introduction |
•Single curve design fits ergonomics; •Choose 100% polymer polyethylene bulletproof material to provide a more lightweight solution; •Cut angle design facilitates the removal and installation of the plug-in board; •Can be used with a bulletproof vest as a front or back panel to increase the level of bulletproofing, or used alone as an independent bulletproof panel; •Standardized size 250*300mm can protect the core parts of the body, different sizes can be customized; •Selected waterproof fabric or polyurea spray painting process, wear-resistant, aging-resistant, anti-corrosion and waterproof, extending the service life of the plug-in board. |
|||||||
2 | Bulletproof insert-alumina | Product name | Composite bulletproof chest plate-alumina ceramic (Alu+PE) | |||||
Bulletproof material | Ultra-high molecular polyethylene (PE) + alumina AL2O3 ceramic sheet | |||||||
Color | Black, military green, camouflage, customizable | |||||||
Dimensions | 250*300mm | 250*300mm | 250*300mm | |||||
Bulletproof area(㎡) | 0.07㎡ | 0.07㎡ | 0.07㎡ | |||||
Thickness(mm) | 18mm | 22mm | 16mm | |||||
Bulletproof level | GA5 (10+8) | GA6 (10+10) | 95 rifle (10+6) | |||||
Weight KGS | 2.40±0.05KG | 2.75±0.05KG | 2.00±0.05KG | |||||
Execution standards | "GA141-2010 Police Body Armor" | |||||||
Spray painting process | Wrapping cloth or polyurea | |||||||
Shelf life | 8 years | |||||||
Delivery | Determined based on order quantity | |||||||
Performance introduction |
•Single curve design fits ergonomics; •Ultra-high molecular polyethylene PE + alumina AL2O3 ceramic sheets can provide a higher bulletproof level; •Cut angle design facilitates the removal and installation of the plug-in board; •Can be used with a bulletproof vest as a front or back panel to increase the level of bulletproofing, or used alone as an independent bulletproof panel; •Standardized size 250*300mm can protect the core parts of the body, different sizes can be customized; •Selected waterproof fabric or polyurea spray painting process, wear-resistant, aging-resistant, anti-corrosion and waterproof, extending the service life of the plug-in board. |
|||||||
3 | Bulletproof insert-silicon carbide | Product name | Composite bulletproof chest plate-silicon carbide ceramic (Sic+PE) | |||||
Bulletproof material | Ultra-high molecular polyethylene (PE) + silicon carbide SIC ceramic sheet | |||||||
Color | Black, military green, camouflage, customizable | |||||||
Dimensions | 250*300mm | 250*300mm | 250*300mm | |||||
Bulletproof area(㎡) | 0.07㎡ | 0.07㎡ | 0.07㎡ | |||||
Thickness(mm) | 18mm | 22mm | 16mm | |||||
Bulletproof level | GA5 (10+8) solo defense | GA6 (10+10) solo defense | 95 rifle (10+6) | |||||
Weight KGS | 2.10±0.05KG | 2.40±0.05KG | 1.70±0.05KG | |||||
Execution standards | "GA141-2010 Police Body Armor" | |||||||
Spray painting process | Wrapping cloth or polyurea | |||||||
Shelf life | 8 years | |||||||
Delivery | Determined based on order quantity | |||||||
Performance introduction |
•Single curve design fits ergonomics; •Selecting ultra-high molecular polyethylene PE + silicon carbide SIC ceramic sheets can provide a higher bulletproof level; •Cut angle design facilitates the removal and installation of the plug-in board; •Can be used with a bulletproof vest as a front or back panel to increase the level of bulletproofing, or used alone as an independent bulletproof panel; •Standardized size 250*300mm can protect the core parts of the body, different sizes can be customized; •Selected waterproof fabric or polyurea spray painting process, wear-resistant, aging-resistant, anti-corrosion and waterproof, extending the service life of the plug-in board. |
